COLOR ACE, C/A series

[LNG:ENG]
[LNG:ENG]

Features

・Easy to change colors as the equipment is developed for handling small lots of many product varieties. Some type of equipments has the capability to make an advance preparation work for the next process.
・Material consumption of the extruder can be controlled precisely by weighing the feed of main material.
・As the above weight signal is used for the feed control of color pallets or expensive additives matched up with the fluctuation of the output volume of extruder.
・Touch operation panel eliminates the operation error and enables prompt response to the trouble.
・As the material are used for efficiently, the consumption of material can be saved.
・Data can be stored on external memory and controllable on PC.


Specifications

Feed Capacity Main Material Additive
25〜250Kg/H 0.15〜8.0Kg/H
Measurement Method Volume measurement by the output volume of extruder or weight measurement by load cell Volume measurement type by screw feeding or weight measurement type by load cell
Measurement Accuracy Volume Type ― Weight type below±0.5% Volume type(Max. screw feeding volume)±1-2%
Weight type(Max. screw feeding volume) below±1%
